The N91.XYZTR4K is a high-precision platform that can move in six dimensions: X, Y, Z, θx, θy, and θz. With precise algorithms, it can achieve high-precision motion control of six axes. It features a displacement of 3mm/axis in the straight direction, and a deflection stroke of ±2°/axis. Its low profile is suitable for integration. With E53 piezo controller, it can be operated by PC software, which is more convenient.
Characteristics
|
|
|
|
|
|
|
|
|
|
| 技术参数 | ||
|
Type |
N91.XYZTR4K |
Units |
|
Active axes |
X、Y、Z、θx、θy、θz |
|
|
Travel in XYZ |
3/axis |
mm |
|
Travel in θxθyθz |
±2/axis |
° |
|
XYZ resolution |
＜30 |
nm |
|
θxθyθz resolution |
0.2 |
μrad |
|
Operating temperature |
0~40 |
℃ |
| Material |
Steel, Al |
|
|
Load capacity(horizontal) |
1.2 | kg |
|
Mass |
2 |
kg±5% |
|
Cable length |
1.5 |
m±10mm |
|
Recommended Controllers |
E53.C4K-H/E53.C1K-K |
|
